Operating system
Microsoft® Windows® CE .NET 4.2
Processor
266 MHz
Memory
System Memory: 64 MB SD RAM
Flash ROM: 32 MB
Display
3.5" 200-nit high-brightness TMR (Transmissive with Micro Reflective) LCD
65,536 colours
320 x 240
Finger-tip touch screen
Size
97.6 (L) x 113 (W) x 50 (H) mm
Weight
300g
10.6oz
GPS
SiRF® StarII LP with XTRAC v2
12 parallel channels
Acquisition time (typical):
• Reacquisition: 1 sec.
• Hot start: 8 sec.
• Warm start: 35 sec.
• Cold start: 55 sec.
Accuracy (typical):
• Position: 10 m for 90%
• Velocity: 0.1 m/s
Protocols
• NMEA-0183 v3.0
GGA, GGL, GSA, GSV, RMC, VTG
Antenna
Integrated
External: Optional (see Acer HH Options)
Storage
SD/MMC Card Slot for SD/MMC-Cards (up to 2 GB possible)
256 MB SD-Card including map data
Audio
Built-in speaker (2 W)
3.5 mm stereo earphone jack
Special keys and buttons
5-way joystick (up, down, left, right, enter)
Volume buttons
Zoom buttons
Navigation menu button
Main menu button
Power button
Software reset button
Power indicator
Green — power on
Red — battery low
Orange — battery charging
Battery
Rechargeable 2.200 mAh Li-ion battery
10-hour battery life when backlight is off
PC connectivity
USB cable via Microsoft® ActiveSync® technology
Software
Destinator™ DS Navigation Software versie: 2006
Features:
• Destination/Address manager
• POI (Point of Interest)
• Favorites
• Destination history
• Car/handheld navigation
• Trip planner
• Avoid routes
MP3 — playback of audio files including MP3, WAV, and Windows® Media audio files
Photo — thumbnail views; rotation and zoom in/out on pictures; slideshow feature
Contacts — exchange contact information with Microsoft Outlook application on a PC
Maps and coverage
NAVTEQ™ digital map (integrated in Destinator™ DS Q3 2005)
Pre-installed on memory Card :
• Destinator™ DS Europe (including (Major roads of Europe & Cross-Country navigation function) (CP.H010K.016)
Companion CD
Contact exchange — exchange contacts between Acer d100 and Microsoft® Outlook® on a PC
Microsoft ActiveSync 3.8
Adobe® Reader®
Acer d150 User's Guide
